Description
Product Overview
Color audio-video unit for 2-wire systems with terminal block complete with directable color camera with front adjustment, LED camera lighting. Complete with terminal block and audio control with echo-cancelling, sealed-unit loudspeaker, electret microphone and front-mounted loudspeaker volume control. Complete with microprocessor and 8-position dip switch for programming calls to users. Programmable audiovisual functions for users with disabilities. Onboard electronic lock-release function (3A) plus C, NC, NO contacts for 10A relay. Timed lock release input and door open indication. Compatible with power supply unit art. 1210. Dimensions: 102x55x38 mm
Main Features
- Complete with terminal block and audio control with echo-cancelling, sealed-unit loudspeaker, electret microphone and front-mounted loudspeaker volume control.
- Complete with microprocessor and 8-position dip switch for programming calls to users. programmable audiovisual functions for users with disabilities. On-board electronic lock-release function (3A) plus C, NC, NO contacts for 10A relay
- imed lock-release input and door open indication. Compatible with power supply unit art. 1210. Dimensions: 102x55x38 mm.
